$59.00 USD

  • 5MP, 2560 × 1944@20fps
  • 3.6mm fixed lens
  • Digital WDR (Wide Dynamic Range)
  • Switchable TVI/AHD/CVI/CVBS
  • Support coax protocol
  • Support OSD menu
  • EXIR, IR up to 132ft
  • IP67
  • HD  Video Surveillance
Camera
Image Sensor 5MP CMOS Image Sensor
Effective Pixels 2560 (H) × 1944 (V)
Min. Illumination 0.01Lux @ (F1.2,AGC ON), 0Lux with IR
Electronic Shutter PAL: 1/25 s to 1/50, 000 s
NTSC: 1/30 s to 1/50, 000 s
Lens 3.6 mm fixed lens
Horizontal Field of View: 80.1° (3.6 mm)
Lens Mount M12
Day & Night IR cut filter
Angle Adjustment Pan:0‐360°, Tilt:0‐75°, Rotation:0‐360°
Synchronization Internal synchronization
Video Frame Rate PAL: 5 MP@20fps, 4MP@25fps, 1080p@25fps
NTSC: 5MP@20fps, 4MP@30fps, 1080p@30fps
HD Video Output 1 HD analog output
Switch Button TVI/AHD/CVI/CVBS
Menu
AGC Support
Day/Night Mode Auto/Color/BW (Black and White)
White Balance ATW/MWB
BLC(Backlight Compensation) Support
DWDR(Digital Wide Dynamic Range) Support
Language English
Functions Brightness, Sharpness, DNR, Mirror, Smart IR
General
Operating Conditions  -40 °F ~ 140 °F ,Humidity 90% or less (non-condensing)
Power Supply 12VDC±25%
Power Consumption Max.4.3W
Protection Level IP67
Material Enclosure: Plastic
Main body: Metal
IR Range Up to 132ft
Communication Up the coax, Protocol: Hikvision-C (TVI output)
Dimensions Camera: Ø 110 mm x 93.2 mm ( Φ4.33”×3.67”)
Weight  Approx. 350 g (0.77 lb.)
Qty available: -15 SKU:AC326-FD4
